Lead A1 Virtual Analog Keyboard Synthesizer

Lead A1 Virtual Analog Keyboard Synthesizer - Image 2

Lead A1 Virtual Analog Keyboard Synthesizer - Image 3

Lead A1 Virtual Analog Keyboard Synthesizer

Original price was: $300.00.Current price is: $96.99.

Keyboard: 49-key octave velocity sensitive keyboard with octave shift buttons (+/- 2 octaves)
Keyboard Split with 2 slots for the upper and lower section
Controls: 1x Modulation wheel
1x Pitch stick (with no dead zone at zero crossing)
1x 1/4″ (6.3 mm) pedal input for sustain pedal
1x 1/4″ (6.3 mm) pedal input for expression pedal
Pitch Bend Range: Programmable up to +/- octave
User Interface: 3x LED displays
23x knobs
3x encoders
20x buttons for program and performance editing

Oscillator

Waveform: Multiple Oscillator waveforms; traditional analog, extended analog, pulse waveforms, wavetable
OSC Configuration Knob Categories: pitch, detune, shape, sync, ring modulation, noise, dual OSC, FM

Filters

Type: Multi-mode Filter:
12 dB (2-pole) low-pass,
24 dB (4-pole) low-pass and band pass, high pass
Ladder M and Ladder 303 characteristics
Control: Cut off, resonance, envelope amount, LFO amount, drive
Envelope: ADR/ASR
Tracking Ability: Filter keyboard tracking can be set to off, 1/3, 2/3 or full
Distortion: Filter Distortion: Adjustable

Modulation

LFO1: Generates: triangle, square, sawtooth, inverted sawtooth or sample and hold waveforms
Routing: can be routed to filter frequency, pitch, shape and OSC mod
Sync: Can be synchronized to the Master Clock
Modes: can be switched to Env mode with three different characteristics and sample and hold is manually triggered by keyboard
Arpeggiator: Range: 1 to 4 octaves
Modes: up, down, up/down, random, Poly
Sync: arpeggio rate can be synchronized to the Master Clock
Envelope: ADR/ASR
Velocity control: on/off
Inverse Envelope: on/off

Amplifier

Control: ADR/ASR envelope
Gain control
Individual Pan Control: per program
Velocity Control: on/off
Performance
Voices: Poly, legato with portamento, Mono, True Unison 1, 2 & 3
Layering: 4x program slots for layering possibilities
Effects
Effects: Types: flanger, phaser, ring modulation, chorus, ensemble and drive
Delay: Types/Controls: Tap tempo, four stages of feedback, ping-pong, dry/wet mix
Sync: delay speed can be synchronized to the Master Clock
Reverb: Types: room, stage 1, stage 2, hall 1, hall 2

Memory

Programs: Single Sounds: 8x 50 (400) locations
Performances (Multiple Sounds): 4x 50 (200) locations
Audio Output
Output: 4x unbalanced 1/4″ (6.3 mm) (each slot can be assigned to its own output)
1x 1/4″ (6.3 mm) stereo headphone output
24-bit DACs

Type: USB MIDI
5-pin DIN in
5-pin DIN out
THRU: soft
Control: All control knobs and switches send and receive control change messages
MIDI Dumps: System exclusive or all programs
Sync: Master Clock will sync to incoming MIDI clock

Dimensions & Weight

Dimensions (L x W x D): 34.0 x 3.7 x 10.7 (864 x 94 x 272 mm)
Weight: 10.7 lb (4.85 kg)

SKU: N13-3072 Category: Keyboard Synthesizers

Multiple payment methods, 100% payment security
Best price, safe shopping guarantee
Top-Notch Quality
Quality products for every lifestyle.

Description
Reviews (0)

Nord Lead A1

The Nord Lead A1 is an analog modeling synthesizer with a 49-note Fatar keybed, 24-voice polyphony, and four synth parts that can be played simultaneously. Each synth part features its own dedicated output for enhanced routing and sound processing options.

The oscillator section utilizes two oscillators, starting with a single waveform then routing it through a configuration shortcut (such as pitch, detune, sync, shape, ring modulation, FM, noise, or dual oscillator mode). The configuration shortcuts offer a simple means of generating powerful sounds without the hassle of patching everything together.

The synthesizer’s filter section is comprised of 12 and 24dB low-, high-, and band-pass filters alongside emulations of the diode and ladder filters found in the Mini and TB-303 synthesizers. Additionally, the effects section features 6 onboard effects—including two analog models of ensemble and chorus effects in addition to classic effects like ring modulation, flanger, phaser, delay, and reverb.
